USB 3.0 Gigabit Ethernet Adapter
Compact plastic ABS housing in white color for reliable wired network connectivity
Product Overview
The MSLFORCE OEM USB 3.0 TYPE-A external network adapter converts USB-A 3.2 Gen 1 ports on laptops to Gigabit Ethernet ports. This USB network adapter supports 10/100/1000 Mbit/s speeds, expanding computers with fast, stable network connections and adding missing RJ-45 connectivity.
Technical Specifications
- USB Type A 9PIN Gold-Plated connector (male)
- RJ45 Connector (8PIN) Gold-Plated (female) Gigabit Ethernet interface
- Supported transmission rates: 10/100/1000 Mb/s
- Compliant with IEEE 802.3, 802.3u, 802.3ab specifications
- Auto-detection for 10/100/1000 Mb/s speeds
- IPv4/IPv6 packet Checksum Offload Engine (COE)
- TCP Large Send Offload V1 and V2 support
- IEEE 802.1P Layer 2 priority encoding & decoding
- IEEE 802.1Q VLAN tagging support
- IEEE 802.3az EEE (Energy Efficient Ethernet)
- Jumbo frame support
- Full-duplex transmissions with IEEE 802.3x flow control
- Auto MDI/MDIX - crossover detection and auto-correction
- Hardware Cyclic Redundancy Check (CRC)
- Pair Swap/Polarity/Skew Correction
Wake-on-LAN Feature Support
- Sleep mode and remote Wake Up via Magic Packet
- Microsoft Wakeup Frame and Wake Packet Detection
- Link Change Wake-up support
- ECMA-393 proxZzzy® standard for sleeping hosts
- RealWoW! technology for remote wake up over Internet
Advanced Power Management
- Advanced Configuration Power Management Interface (ACPI)
- Power Management offload (ARP & NS)
- Microsoft Always On Always Connected (AOAC)
- Intel Converged Platform Power Management (CPPM)
- Link Power Management (LPM)
- Operating System-directed Power Management (OSPM)
- IEEE 802.3az EEE (Energy Efficient Ethernet)
Supported Operating Systems
Windows, macOS, Linux and Chrome OS
Key Applications
No LAN Port on Modern Laptops: Essential for ultrabooks and MacBooks with only USB-C or USB-A ports
Stable Wired Internet: Faster, more stable connections for online meetings, gaming, and data transfers
IT & Office Use: Critical for IT admins, technicians, and secure environments
Cross-Platform Compatibility: Works with Windows, macOS, Linux, and Chrome OS
Portable & Travel-Friendly: Ideal for business travelers connecting to hotel or office networks
Gaming Consoles & TV Boxes: Upgrade devices with poor Wi-Fi performance to stable wired connections
MSLFORCE Competitive Advantages
- Premium chipset for stable high-speed performance
- Compact, lightweight ABS housing - strong and minimalistic
- Plug and play for most operating systems
- Global compatibility with multilingual manual
- OEM/ODM supported - custom logo, casing color, or packaging
Product Specifications
| Product Name |
USB 3.0 TYPE-A male to 1x RJ45 Ethernet Female External Network Adapter |
| Output |
RJ-45 |
| Rate |
5000 / 480 / 12 Mbit/s (super / high / full speed) |
| Indication |
LED |
| Chip |
Realtek RTL8153 QFN48PIN |
| Power Source |
USB bus power |
| Dimensions |
59.7*24.5*14.3MM (USB Cable Length 20CM not included) |
| Weight |
22g |
The USB 3.0 TYPE-A to LAN adapter with compact dimensions and minimal weight is an ideal accessory for laptops where stable wired Ethernet connectivity is required.
